ANNABELLA PLUS 5.0 black ductable stove

Ducted pellet stove, slim

Features: • Fire door, combustion chamber, and burner in cast iron • Tube bundle heat exchanger (manual cleaning) • Ventilation with Pro Air Setup • Ducting up to 6 meters, manually adjustable • Ducting outlet options (Ø80 mm): rear, top, right side • Reduced depth • Flue gas outlet options: rear, top right side • Removable combustion chamber by authorized assistance • Easy Setup • Easy Control • Self Control • Backlit IR Touch remote control • Black LCD

·        3.3-9.0 kW Nominal thermal power

·        258 m3m³ heated

·        Efficiency 93.0 - 92.0 %

·        Hourly consumption 0.7 - 2.0 kg/h

·        Dimensions (LxHxP) 703x1078x343 mm

·        Net Weight 132 kg

·        Flue gas diameter (Ø) 80 mm P/S/Right side

·        Total tank capacity ~ 14 kg

·        Energy Class A+

·        Environmental Certification DM186 5 STARS

·        Safety thermostat tank Always ensures a high safety standard, preventing overheating of the product in case of anomalies.

·        Auto-balancing air 1° and 2° Primary and secondary air electronically balanced for optimal combustion and thermal efficiency.

·        Flue safety pressure switch Checks the correct evacuation of flue gases and, if necessary, blocks the pellet loading to avoid issues with the generator.

·        Chronothermostat Chronothermostat with temperature control divided into four daily time slots for optimal management of environments.

·        Auto-restart after blackout The device automatically restarts after a power outage, following the required control cycle.

·        Room thermostat The presence of the room sensor optimizes comfort and leads to a significant reduction in consumption.

·        Clean combustion Increases combustion efficiency and the lifespan of wear parts, while also reducing the routine cleaning of the burner.

·        Glass cleaning system It is a system that effectively prevents the formation of deposits on the fire door glass through a specific path of preheated air.

·        Removable burner for easy cleaning The construction system of the burner allows for easy extraction for quick and thorough cleaning.

·        Self-regulating flue fan (encoder) Keeps the flue motor speed constant to ensure proper combustion of the product.
